Theory of Machines may be defined as that branch of Engineering-science, which deals with the study of relative motion between the various parts of a machine, and forces which act on them. The knowledge of this subject is very essential for an engineer in designing the various parts of a machine. Classification of Theory of Machines…
Governor, in technology, device that automatically maintains the rotary speed of an engine or other prime mover within reasonably close limits regardless of the load. A typical governor regulates an engine’s speed by varying the rate at which fuel is furnished to it. Nearly all governors depend for their action on centrifugal force and consist of a pair…
Proell Governor is a different type of governor in which the fly balls are connected to the spindle using an extended arm. The fly balls are mounted on this additional arm. Like the porter governor, proell governor also has central weight which increases the speed of rotation. Proell Governor functions much more accurately than other…
Bevel gears are useful when the direction ofa shaft’s rotation needs to be changed. They are usually mounted on shafts that are 90 degrees apart, but can be designed to work at other angles as well. The teeth on bevel gears can be straight, spiral or hypoid. Straight bevel gear teeth actually have the same problem…
Cam – A mechanical device used to transmit motion to a follower by direct contact. Where Cam – driver member Follower – driven member. The cam and the follower have line contact and constitute a higher pair. In a cam – follower pair, the cam normally rotates at uniform speed by a shaft, while the…
To assure continuous smooth tooth action, as one pair of teeth ceases action a succeeding pair of teeth must already have come into engagement. It is desirable to have as much overlap as is possible. A measure of this overlap action is the contact ratio. This is a ratio of the length of the line-of-action…
It is the ratio between the velocities of the driver and the follower or driven. It may be expressed, mathematically, as discussed below: Let d1 = Diameter of the driver, d2 = Diameter of the follower, N1 = Speed of the driver in r.p.m., and N2 = Speed of the follower in r.p.m. Length of the belt that…
